TYPES	Stroke mm	L extended mm	Compression force max. N
HB-70-100	111	331	50,000
HB-70-200	211	531	50,000
HB-70-300	311	731	50,000
HB-70-400	411	931	30,300
HB-70-500	511	1,131	21,600
HB-70-600	611	1,331	16,200
HB-70-700	711	1,531	12,600
HB-70-800	811	1,731	10,100

Hydraulic Dampers
HB-70-100

Linear motion control

Adjustable
Compression force max. 50,000 N
Stroke 111 mm

High quality and long service life: The hydraulic dampers of the product family HB can also be used as single or double acting brake. Its coated body in a slim gas spring design and the piston rods with wear-resistant surface coating are features of high quality and long service life.

The maintenance free, ready-to-install and closed systems provide a constant feed rate and are adjustable, and the control segment on the piston makes adjustment at the end position child’s play. Thanks to many add-on components the assembly is easy to mount, so that the damper can be universally deployed for damping back and forth swinging masses, such as in power or free conveyors.

This product is not available for
online order.

If you are interested in ordering this
product, click the inquiry form below
and we will contact you.

CAD Drawings

Product-Downloads

HB-70-100

Adjustable

Dimensions

Stroke	111 mm
L extended	331 mm

Technical data

Compression force max. 50,000 N

Traction force max. 50,000 N

Outer body diameter Ø 70 mm mm

Piston rod diameter Ø 30 mm

Lifetime Approx. 10,000 m

Free travel Construction of the damper results in a free travel of approx. 20 % of stroke.

Separator piston Extension force min. 250 N; dimension L + 150 mm. Part number: add suffix -T.

Operating temperature range -20 °C to +80 °C

Adjustment Achieved by turning the piston rod in its fully extended or fully compressed position.
Clockwise rotation = increase of the damping
Anti-clockwise rotation = decrease of the damping
Damping force adjustable before installation. The adjustment can add a max. of 5 mm to the L dimension.

Positive stop External positive stops 5 mm to 6 mm before the end of stroke provided by the customer.

Damping medium hydraulic oil

Material Outer body: coated steel; Piston rod: hard chrome plated steel; End fittings: zinc plated steel

Mounting in any position

Note

Increased break-away force if unit has not moved for some time.

End fittings

They are interchangeable and if necessary must be positively secured by the customer to prevent unscrewing.

On request

Special oils, other special options and special accessories are available on request.
